Product Overview
Hytera SM26N1 is a remote speaker microphone.
Key Features
- PTT Key: available
- Speaker Power: 2W (rated); 3W (max.)
- IP Rating: IP67
Key Specifications
| Manufacturer | Hytera |
|---|---|
| Model | SM26N1 |
| Dimensions | 76.85* 60.55* 34mm |
| Weight | about 150 g |
| Color | black & grey |
| PTT Key | available |
| Emergency Key | available |
| Microphone Sensitivity | –42±3 dB @ 1 kHz 3.0 V 2.2 K, 0 dB = 1 V/Pa |
| Speaker Power | 2W (rated); 3W (max.) |
| Speaker Impedance | 20 Ω±15% @ 1.5 kHz |
| Manufacturer-listed speaker acoustic test value | 97±3 dB @ 1 kHz 2 W/30 cm |
| IP Rating | IP67 |
| Operating Temperature | –30℃ to 60℃ |
| Storage Temperature | –40℃ to 85℃ |
| Listed radios | PD605; PD665; PD685; X1e; X1p; Z1p |
| Attachment | 360-degree swivel metal clip |
Compatibility and Configuration
Confirm exact compatible equipment, connector and required intervening components. Listed models (not an exhaustive compatibility list): PD605, PD665, PD685, X1e, X1p, Z1p.
Ordering Information
Confirm exact part number, connector, host variant and supplied components.
