Product Overview
Hytera DIB-R5 Outdoor is an IP65-rated TETRA base station for wall or mast installation. It supports up to two carriers, single or dual receive diversity and GNSS synchronisation, with a 48 V DC supply.
Product Details
| Manufacturer | Hytera |
|---|---|
| Model | DIB-R5 Outdoor |
| Frequency variants | 380–430, 450–470 or 806–870 MHz |
| Output at antenna connection | 20 W (43 dBm) |
| Supply | 48 VDC |
| Weight | 10 kg |
| Protection | IP65 |
| Operating temperature | -30 to +60 °C |
| Synchronisation | GNSS: GPS, Galileo, GLONASS, BeiDou |
| Dimensions by mounting bracket | 426 x 250 x 167 mm with mast bracket; 426 x 250 x 135 mm with wall bracket |
| Maximum carrier capacity | Up to two; configuration-dependent |
| Receive diversity | Single or dual |
| Cooling | Passive cooling |
Request a Quote
Please specify your existing platform, device count, deployment environment and required functions. Hardware, software licences and implementation scope are confirmed in the quotation.
