Product Overview
Hytera ACM-01 is an IP54 PTT and microphone controller with a 3.5 mm receive-only earpiece socket. The earphone is not included.
Key Features
- PTT Key: available
- VOX: none
- IP Rating: IP54
Key Specifications
| Manufacturer | Hytera |
|---|---|
| Model | ACM-01 |
| Weight | about 35 g |
| Color | black |
| PTT Key | available |
| VOX | none |
| Emergency Key | none |
| Microphone Sensitivity | –45±3 dB @ 1 kHz 3.0 V 2.2 KΩ, 0 dB = 1 V/Pa |
| IP Rating | IP54 |
| Operating Temperature | –20℃ to 60℃ |
| Storage Temperature | –40℃ to 75℃ |
| Note | Compatible with receive-only earpiece(φ3.5mm jack) |
| Earpiece supply | Earphone not included |
| Listed earpieces | ES-01; ES-02; EH-01; EH-02; EHS20 |
| Listed digital radios | BD505LF; BD505; BD555; BD615; PD405; PD415; PD485; PD505LF; PD505; PD565 |
| Listed analogue radios | TC-446S; POWER446; TC-508; TC-510; TC-518; TC-580; TC-610; TC-620; TC-700 |
Compatibility and Configuration
Confirm the exact compatible radio and accessory combination before ordering. Individually named catalogue models: BD505LF, BD505, BD615, PD405, PD415, PD485, PD505LF, PD505, PD565, TC-518, TC-610, TC-620.
Ordering Information
Confirm the exact part number, radio variant, connector pinout, required PTT/VOX features and supplied components before ordering. A separate compatible earpiece is required.
Request a Quote
Contact MARS SC about Hytera ACM-01 and your required radio configuration.
