More about the product
Cellular WAN
- FDD/TDD/UMTS/GSM
- LTE CAT12/13, DL 3CA, UL 2CA supported
- DL 4MIMO & 256QAM supported
Band configuration
- FDD LTE Band 1,3,7,8,20,28,32
- TDD LTE Band 38,40,41
- UMTS Band 1,8
- EDGE/GPRS/GSM Quad Bands
- LTE 4MIMO:1,3,7,32,38,40,41
Peak data rate
- FDD-LTE DL/UL 600/150Mbps (CAT12/13)
- TDD-LTE DL/UL 400+/30+Mbps (CAT12/13)
Wi-Fi
802.11 a/b/g/n/ac/ax2.4GHz 2×2 & 5GHz 2×2, DBDC, Total 3.0Gbpsup to 64 users supported
Dimension: 184 × 147 × 41mm
Interface
- 4 x RJ45 (GE, 1 x WAN/LAN, 1 x LAN)
- 1 x RJ11 (FXS, CSFB/VoLTE/VoIP(Customized))
- 1 x SIM Slot
- 2 x TS-9
- 1 x DC470
Other Configuration
- LED: Power, Wi-Fi, Network
- Button & Switch: WPS, Reset
- NFC for Wi-Fi connection(Optional)
- Features
- Data service
- Voice Service
- WebUI & ZTE Link APP
- FOTA/TR069(Customized)
- Firewall
- IPV6/4
- Main stream OS supported
