Description
The table below lists accessories that are approved for use in potentially hazardous environments according to the ATEX EC Directive 2014/34/EU and the IECEx certification scheme.
Kit Number | Description | Separate ATEX/ IECEx Certificates |
Batteries | ||
NNTN7383A NNTN7383B | ATEX Li-Ion Battery | BVS 08 ATEX E 097 IECEx BVS 08.0037 |
Carrying Options | ||
PMLN5287A | Hard Leather Case, Black | See radio certificates |
PMLN5288A | Soft Leather Case, Black | See radio certificates |
PMLN5004A PMLN5004B | Shoulder Wearing Device | See radio certificates |
PMLN5134A | Belt Clip (2.5 inch) | See radio certificates |
NTN5243A | Shoulder Strap | See radio certificates |
Audio Accessories Notes: •Read safety instructions and conditions of the certifications of the particular accessories before use of the accessories •Only accessories with a KitNumber listed can be ordered from Motorola Solutions | ||
PMMN4058A | Remote Speaker Microphone with Volume Control | BVS 08 ATEX E 107 IECEx BVS 08.0040 |
PMLN5389A PMLN5389B | Over the Head Heavy-duty Headset | BVS 08 ATEX E 160 IECEx BVS 08.0017 |
PMLN5390A PMLN5390B | Behind the Head Heavy-duty Headset | BVS 08 ATEX E 160 IECEx BVS 08.0017 |
PMLN5391A PMLN5391B | Over the Head Lightweight Headset | BVS 08 ATEX E 160 IECEx BVS 08.0017 |
PMLN5392A PMLN5392B | Behind the Head Lightweight Headset | BVS 08 ATEX E 160 IECEx BVS 08.0017 |
PMMN4063A PMMN4063B | Throat Microphone with 80 mm PTT Button | BVS 08 ATEX E 160 IECEx BVS 08.0017 |
PMLN5679A | Audio Adapter | BVS 11 ATEX E 059 X IECEx BVS 11.0031X |
Kit Number | Description | Separate ATEX/ IECEx Certificates |
GMMN8543ASP01 | Ceotronics: CT-MultiCom/Ex MTP850 Note : Not approved for use in dust hazardous environments | IMQ 11ATEX 001 X |
GMMN4589A | SAVOX: 400AV/MTP850,810 ATEX | VTT 07 ATEX 071X |
— | MSA Auer: AlphaScout TETRA BUND | BVS 14 ATEX E 094 X |
3M/Peltor Branded
The following 3M/Peltor branded accessories are approved for use with the radios. The safety instructions below are an extension to 6866588D20 for connection of the PTT Adapter FL4062-50-34 with the headsets listed below.
The revisions of the accessories and the ATEX/IECEx certificates listed below are the revisions at the time this leaflet was released.
Kit Number | Description | Separate ATEX/IECEx Certificates |
PMLN6087A | MT7H79F-50 Standard Headset, with Microphone and Speaker | Nemko 09 ATEX1114X Issue 2 IECEx NEM 09.0004X Issue 2 |
PMLN6089A | MT1H7P3E2-07-51 Headset Series, Tactical XP | Nemko 10 ATEX1029X Issue 2 IECEx NEM 11.0010X Issue 1 |
PMLN6090A | MT1H7F2-07-51 Headset Series, Tactical XP | Nemko 10 ATEX1029X Issue 2 IECEx NEM 11.0010X Issue 1 |
PMLN6092A | MT7H79P3E-50 Standard Headset, with Microphone and Speaker | Nemko 09 ATEX1114X Issue 2 IECEx NEM 09.0004X Issue 2 |
PMLN6333A | MT72H540P3E-50 Headset with Microphone and Speaker, Twin cup | Nemko 09 ATEX1119X Issue 2 IECEx NEM 09.0005X Issue 2 |
PMLN6728A | FL4062-50-34 PTT Adapter for use with Headset | Nemko 13 ATEX1521X Issue 1 IECEx NEM 13.0001X Issue 1 |
Kit Number | Description | Separate ATEX/ IECEx Certificates |
Antennas | ||
85007012001 | Short Stubby Antenna, 380–430 MHz | See radio certificates |
8587526V14 | Medium Stubby Antenna, 380–430 MHz | See radio certificates |
8575279M01 | Whip Antenna, 380–430 MHz | See radio certificates |
85012000001 | Whip Antenna, 806–870 MHz | See radio certificates |
8575277M02 | Stubby Antenna, 806–870 MHz | See radio certificates |
Covers | ||
PMLN5419A | Dust Cover | See radio certificates |
The table below lists accessories that are approved by Motorola for use with MTP850 Ex/MTP810 Ex TETRA Terminal Family only outside potentially hazardous environments.
Kit Number | Description |
Chargers | |
WPLN4199B | Impres™ Single Unit Charger – Base Only |
WPLN4182A | Impres™ Single Unit Charger – US Plug |
WPLN4183A | Impres™ Single Unit Charger – UK Plug |
WPLN4184A | Impres™ Single Unit Charger – EU Plug |
WPLN4185A | Impres™ Single Unit Charger – Australia Plug |
WPLN4186A | Impres™ Single Unit Charger – Argentina Plug |
NNTN7471A NNTN7471B | Impres™ Single Unit Charger – Korea Plug |
WPLN4197A | Impres™ Multi Unit Charger – Base Only |
WPLN4187A | Impres™ Multi Unit Charger – US Cord |
WPLN4189AA | Impres™ Multi Unit Charger – EU Cord |
WPLN4188AA | Impres™ Multi Unit Charger – UK Cord |
WPLN4190A | Impres™ Multi Unit Charger – Australia Cord |
WPLN4191A | Impres™ Multi Unit Charger – Argentina Cord |
WPLN4205A | Impres™ Multi Unit Charger – International (110 V) |
WPLN4146A | Impres™ Multi Unit Charger – Korea Cord |
WPLN4198A | Impres™ Multi Unit Charger with Display – Base Only |
WPLN4192A | Impres™ Multi Unit Charger with Display – US Cord |
WPLN4194AA | Impres™ Multi Unit Charger with Display – EU Cord |
WPLN4193AA | Impres™ Multi Unit Charger with Display – UK Cord |
WPLN4195A | Impres™ Multi Unit Charger with Display – Australia Cord |
WPLN4196A | Impres™ Multi Unit Charger with Display – Argentina Cord |
WPLN4204A | Impres™ Multi Unit Charger with Display – International (110 V) |
WPLN4145A | Impres™ Multi Unit Charger with Display – Korea Cord |
PMLN5198A PMLN5198B | Impres™ Single Unit Charger – SMPS US AC Cord |
Kit Number | Description |
PMLN5194A PMLN5194B | Impres™ Single Unit Charger – SMPS UK AC Cord |
PMLN5188A PMLN5188B | Impres™ Single Unit Charger – SMPS EU AC Cord |
PMLN5214A | Impres™ Single Unit Charger – SMPS Argentina AC Cord |
PMLN5199A PMLN5199B PMLN5199C | Impres™ Single Unit Charger – SMPS Australia/NZ Cord |
NNTN7470A NNTN7470B | Impres™ Single Unit Charger – SMPS China Cord |
MDRLN4883_ | Non Impres™ Vehicular Travel Charger with Cigarette Lighter |
RLN5233A | Non Impres™ Vehicular Charger |
Cables | |
PMLN5237A | RS232 Data Cable |
PMLN5235A | USB Data Cable |
