Key Features
One Charge Double Shifts
750 mAh Li-polymer battery for 18 hours (0.5W) or 16 hours (1W) of working time and 100 hours of standby time. Universal USB Type-C charging port leaves you worry-free and unconstrained.
Ultra Mini and Light
Only 48 g weight. Go light as air. You can wear an S1 mini/S1 mini LF on the chest, pocket, belt, or lapel. The chic style is suitable for any outfits.
Chat Privately
10 g standard headset — ergonomically engineered with ultra-soft silicone for perfect fit and long-time comfort, adjustable for either ear and delivering clear and pristine audio.
HD Screen
Anti-dirt. Anti-abrasion. Anti-oil. Let you clearly see the channel number, ID, battery level, or other key information.
AirClone
Clone configuration data from one S1 mini to many. All done in a flash.
Channel Copy
Quickly communicate with your existing radios, regardless of brands and models. S1 mini protects your assets in its own way.
Simple Management
Manage your radio with an Android phone that’s always at your fingertips. Programming, batch configuration, backing up frequency information, and more can be performed via Bluetooth.
Unique Label Design
The packing box contains three different colored labels that can be attached to the side of the S1 mini. Easy to spot your radio from the crowd.
Stay Connected – Talk Freely
10,000 square meters of indoor communication range. The S1 mini/S1 mini LF delivers reliable, seamless communications to improve team coordination and collaboration in the workplace.
| General | |
|---|---|
| Model | HYT-S10 (licensed) HYT-S10 LF (PMR446 license free) |
| Frequency range | Ua: 400-440 MHz Uc: 430-470 MHz PMR446: 446 MHz |
| Operating modes | Analogue |
| Operating Voltage | 3.8V (rated) |
| Channels & zones | Channel capacity: 16 Zone capacity: 1 |
| Battey Life(5/5/90 Duty Cycle,High TX Power) | 16 hrs (Tx power 1.0 W) 18 hrs (Tx power 0.5 W) |
| Frequency Stability | ±2ppm |
| Antenna Impedance | 50 Ω |
| Dimensions(H×W×D) mm | 99*30*16mm (without belt clip) |
| Weight | 48g |
| Display | 0.88 inch |
| Bluetooth | BT 5.0 (only data) |
| Receiver | |
|---|---|
| Sensitivity(Analog) | 0.14μV (12dB SINAD) |
| Adjacent Channel Selectivity | ETSI: 60dB@12.5kHz / 70dB@20/25kHz |
| Intermodulation | ETSI: 65dB@12.5/20/25kHz |
| Spurious Response Rejection | ETSI: 70dB@12.5/20/25kHz |
| Blocking | ETSI：84dB |
| Hum&Noise | 40 dB@12.5 kHz; 43 dB@20 kHz; 45 dB@25 kHz |
| Rated Audio Power Output | 0.5W |
| Audio Response | +1~-3 dB |
| Conducted Spurious Emission | <-57 dBm |
| Transmitter | |
|---|---|
| Power Output | 1.0 W (400-440 MHz, 430-470 MHz) 0.5 W (446MHz) |
| FM Modulation | 11K0F3E@12.5 kHz; 14K0F3E@20 kHz; 16K0F3E@25 kHz; |
| Conducted/Radiated Emission | -36 dBm＜1 GHz; -30 dBm＞1 GHz |
| Modulation Limiting | ±2.5 kHz@12.5 kHz; ±4.0 kHz@20 kHz; ±5.0 kHz@25 kHz |
| FM Hum&Noise | 40 dB@12.5 kHz; 43 dB@20 kHz; 45 dB@25 kHz |
| Adjacent Channel Power | 60 dB@12.5 kHz; 70 dB@20/25 kHz |
| Audio Distortion | ≤3% |
| Environment | |
|---|---|
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -30°C to +70°C |
| ESD | ±4kV (Contact) ±8kV (Air) |
