Key Features
EXTENDED COMMUNICATIONS DISTANCE
Brand-new radio frequency scheme and antenna design | Sensitivity up to 0.18 μV | Communication distance increased by 11%
CLEAR AND LOUD AUDIO
Noise cancellation | Loudness up to 90 dB (at 30 cm away, 300 Hz –3 kHz), increased by 3.4%
IMPROVED USER EXPERIENCE
Flame-retardant polycarbonate plastic housing | Worm finish | Double-shot injection | Long-life keys | Center-placed antenna and knob from the side view | Independent volume keys | 9-pin accessory connector
FAST CHARGING
95% charged in 2.5 hours and fully charged in just 3.15 hours. Thanks to USB Type C connectivity. it can be easily charged with standard USB cables and power supply units and even USB power banks.
| General | |
|---|---|
| Frequency Range | 400-470 MHz 136-174 MHz |
| Channels & zones | Channel capacity: 32 Zone capacity: 2 Channels per zone: 16 |
| Channel Spacing | 12.5kHz / 20kHz / 25kHz |
| Operating Voltage | 3.7 V (rated) |
| Battery | 4000 mAh 3.7V |
| Battery Life (5/5/90 Duty Cycle, High TX Power) | 18 h |
| Frequency Stability | ±0.5 ppm |
| Antenna Impedance | 50 Ω |
| Dimensions (H x W x D) (mm) | 105 x 55 x 29.5 mm |
| Weight (with antenna & battery) | 200g ±5 g |
| Bluetooth (Optional) | BT 5.0 BLE+EDR |
| Receiver | |
|---|---|
| Sensitivity | 0.18 μV (12 dB SINAD) |
| Adjacent Channel Selectivity | TIA-603: 60 dB @12.5kHz; 70 dB @20/25kHz ETSI: 60 dB @12.5kHz; 70 dB @20/25kHz |
| Intermodulation | TIA-603: 70 dB @12.5/20/25kHz ETSI: 65 dB @12.5/20/25kHz |
| Hum and Noise | 40 dB @12.5kHz; 43 dB @20kHz; 45 dB @25kHz |
| Rated Audio Power Output | 0.5 W |
| Rated Audio Distortion | ≤3 % |
| Audio Response | +1~-3 dB |
| Conducted Spurious Emission | < -57 dBm |
| Transmitter | |
|---|---|
| RF Power Output | VHF: 4-5W / 1W UHF: 3-4W / 1W |
| FM Modulation | 11K0F3E @12.5 kHz 14K0F3E @20 kHz 16K0F3E @25 kHz |
| Conducted/Radiated Emission | -36 dBm＜1GHz; -30 dBm＞1GHz |
| Modulation Limiting | ±2.5 kHz @12.5 kHz; ±4.0 kHz @20 kHz; ±5.0 kHz @25 kHz |
| FM Hum & Noise | 40dB @12.5 kHz; 43dB @20 kHz; 45 dB @25 kHz |
| Adjacent Channel Power | 60dB @12.5 kHz; 70dB @20/25 kHz |
| Environmental | |
|---|---|
| Operating Temperature | -20℃ to +60℃ |
| Storage Temperature | -40℃ to +85℃ |
| ESD | IEC 61000-4-2 (Level 4) ±8kV (contact); ±15kV (air) |
| Dust and Water Intrusion | IEC60529-IP54 |
| Humidity | MIL-STD-810 H |
| Shock and Vibration | MIL-STD-810 H |
